WK-KBLUBA-6C1L_Shenzhen VKoming Technology CO.,Ltd.

WK-KBLUBA-6C1L

Intel® Sky lake-U/ Kaby lake-U/Kaby lake R Processor，FCBGA1356；Intel® SOC；2*SO-DIMM；4*USB3.0；6*USB2.0；1*SATA3.0；6*COM232；1*M.2

processor：Intel® Sky lake-U/ Kaby lake-U/Kaby lake R Processor，FCBGA1356

chipset：Intel® SOC

Display: Intel® HD Graphics

memory：2*SO-DIMM DDR4 2133/2400MHz Max 32GB

Display output：VGA/EDP2、LVDS/EDP1、HDMI(Support 3 display synchronous/asynchronous output)

storage：1*SATA3.0；1*M.2 Key M ( Supports PCIe X4/ SATA SSD adaptive)

USB:4*USB3.0；6*USB2.0

supports 6*COM232 （COM2 supports RS232/485 as an option）

On board 1*RTL8111 gigabit network card

Expansion slot：1*Mini_PCIe （Support Wifi+Bluetooth / 4G expansion module） 1*SIM card slot

General
CPU	Intel® Sky lake-U/ Kaby lake-U/Kaby lake R Processor，FCBGA1356
Chipset	Intel® SOC
Memory	2*SO-DIMM DDR4 2133/2400MHz Max 32GB
Storage	1SATA3.0 1M.2 Key M (Supports PCIe X4/ SATA SSD adaptive)
Expansion Interface	1Mini_PCIe （Support Wifi+Bluetooth / 4G expansion module） 1SIM card slot
BIOS	AMI BIOS
System	Windows 7/10/11 32bit/64bit/Linux
I/O Interface
Ethernet	1*Realtek® RTL8111 1Gbps Ethernet Controller，RJ45
Serial	6*COM232 （COM2 supports RS232/485 as an option）
USB	4USB 3.0, 6USB 2.0
Audio	Onboard audio decoding controller ALC897 + NS4251 default power amplifier support 3 w @ 4 Ω; 1.7W@8Ω max
Others	1ATX Header 1HDMI Header 1VGA Header 1F_AUDIO Header 1SPEAKER Header 2INVERT Header 1EDP2 Header（VGA and EDP2 hardware are optional） 1LVDS_EDP1 Header 1SATA3.0 interface 1SATA_PWR Header 1BKCL1 Header 1DEBUG Header 1PS/2 Header 2USB2.0 Header（Extensible 4USB2.0） 1USB3.0 Header（Extensible 2USB3.0） 6COM232 Header 1LPT打印 Header 1F-PANEL Header 1GPIO Header 2FAN Header 1*AUTO_ON Header
Display
Display Interface	VGA/EDP2、LVDS/EDP1、HDMI(Support 3 display synchronous/asynchronous output)
Mechanical & Environment
Dimension	170X170MM
Power Input	DC 12V input power supply
Temperature	Operation: 0℃~60℃, Storage: -20℃~75℃
Relative Humidity	0% ~ 95%, non-condensing
