WK-TGLB3-6C2L

1*SATA3.0

1*M.2 Key M  (Supports SATA3 and PCIe Gen4 x4 for SSD)

1*M.2 Key E （Supports WiFi+Bluetooth extension, support WiFi6）

1*M.2 Key B (Supports 3G/4G expansion, and 5G is optional) 1*SIM card slot

Onboard audio decoding controller ALC897 + NS4251 default power amplifier support 3 w @ 4 Ω; 1.7W@8Ω max

1*4PIN ATX Header

6*COM232 Header

1*JVGA Header

3*F_USB2.0 Header（Extensible 6*USB2.0)

1*F_AUDIO Header

1*HSPK Header

2*INVT Header

1*SATA3.0 interface

1*SATA_PWR Header

1*EDP2 Header

1*LVDS_EDP1 Header

1*HLPT_GPIO Header

1*AUTO_ON Header

1*F_PANEL Header

1*PS/2 Header

1*JME Header

1*JESPI1 Header

1*CPU FAN Header

1*SFAN Header

1*LCTL1 Header

1*F_USB3.2 Header（Extensible 2*USB3.2）

LVDS/EDP1、EDP2、HDMI/(HDMI+DP)、VGA(Support 4 display synchronous/asynchronous output)

170X170MM

DC 12V input power supply
